MIETHKE THOMALE GUIDE
Sammen med THOMALE GUIDE-appen for iPhone og iPad tilbyr vi et presist navigasjonsinstrument som forhindrer feilplassering av kateteret. Ved å importere en CT eller MRI til THOMALE GUIDE-appen kan banevinkelen, lengden på kateteret og avstanden til midtlinjen beregnes med noen få trinn.
Utformingen er basert på prinsippet om at i sagittalplanet når en rett vinkel til overflaten (tangent) ventriklene riktig, mens i koronalplanet må en individuell vinkel justeres for å tillate riktig plassering.
